SmartAVI 4K60 DisplayPort, 2-port, single-head, KVM switch with emulation, audio & USB 2.0 support
Hind ei sisalda käibemaksu.
Toode on tellitav.
Tehnilised andmed
| VIDEO | |
|---|---|
| Format | DisplayPort |
| Input Interface | (2) DisplayPort |
| Output Interface | (1) DisplayPort |
| Resolution | 3840 x 2160 @ 60 Hz |
| Color Mode | 24-bit |
| DDC | 5 volts p-p (TTL) |
| Input Equalization | Automatic |
| Input Cable Length | Up to 20 ft. |
| Output Cable Length | Up to 20 ft. |
| Data Rate | 1.65 Gbps per color |
| Console Monitors | Supports both digital and analog monitors |
| AUDIO | |
| Input Interface | (4) 3.5 mm Stereo Audio |
| Output Interface | (1) 3.5 mm Stereo Audio |
| Impedance | 600 Ohm |
| Frequency Response | 20 Hz to 20 kHz |
| Nominal Level | 0-1.0 V |
| Common Mode | Rejection at 60 dB |
| SOFTWARE COMPATIBILITY | |
| Operating Systems | Operates with virtually any OS including Windows, DOS, Linux, Unix, Sun, Mac, etc. |
| USB | |
| Signal Type | USB 2.0, 1.1, and 1.0 w/ internal hub |
| Input Interface | (4) USB Type B |
| Output Interface | (2) USB 1.1 Type A for KVM Devices; (2) USB 2.0 Type A Transparent |
| CONTROL | |
| Front Panel | Push Buttons with LED Indicators |
| RS-232 | Via Control @ 115200 bps |
| Hot Keys | Via Keyboard |
| OTHER | |
| Power | External 100-240 VAC/12VDC2A @ 24W |
| Dimensions | 4” W x 3” H x 6.5” D |
| Weight | 1.95 lbs |
| Approvals | UL, CE, ROHS Compliant |
| Operating Temperature | 0 to +40°C |
| Storage Temperature | -20 to +60°C |
| Humidity | Up to 80% (No Condensation) |
| Emulation | Video, Keyboard and Mouse |
