Tehnilised andmed
| General | |
| Device Type: | Switch - 16 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Subtype: | 10 Gigabit Ethernet |
| Ports: | 12 x 10/100/1000 (PoE+) + 2 x 1 Gigabit / 10 Gigabit SFP+ + 2 x 1000Base-T |
| Power Over Ethernet (PoE): | PoE+ |
| PoE Budget: | 139 W |
| Performance: | Switching capacity: 68 Gbps Throughput: 45.1 Mpps Latency (1 Gbps): 2.3 µs Latency (10 Gbps): 2.6 µs |
| Capacity: | Switched virtual interfaces (SVIs): 16 ARP entries: 1024 IPv4 routes (Unicast): 512 IPv6 routes (Unicast): 512 IGMP groups: 512 MLD groups: 512 IPv4 ACL entries (ingress): 256 IPv6 ACL entries (ingress): 128 MAC ACL entries (ingress): 256 |
| MAC Address Table Size: | 8192 entries |
| Routing Protocol: | IGMPv2, IGMPv3 |
| Encryption Algorithm: | SSL |
| Authentication Method: | Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+, RADIUS |
| Features: | DNS client, VLAN support, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), LACP support, Energy Efficient Ethernet, flow control, UDP, TFTP support, ARP support, DHCP client, ICMP, SNTP support, BOOTP support, DiffServ support, EntityMIB, IPv6 addressing, IPv6 support, LLDP support, LLDP-MED, MIB, MLD snooping, NDP, NAC, port based access control, sFlow, SNMP support, fanless |
| Compliant Standards: | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
| Processor: | 1 x ARM A9: 1.016 GHz |
| RAM: | 4 GB DDR3 SDRAM |
| Flash Memory: | 16 GB |
| Expansion / Connectivity | |
| Interfaces: | 12 x 10/100/1000 Base-T RJ-45 2 x 1/10Gbit LAN SFP+ 1 x USB-C console 1 x USB Type A 2 x Gigabit LAN |
| Power | |
| Power Device: | Internal power supply |
| Power Provided: | 165 watt 0.9 A |
| Voltage Required: | AC 230V (50/60 Hz) |
| Power Consumption Operational: | 16 watt |
| Miscellaneous | |
| Compliant Standards: | IEC/EN 60950-1, EN 60825, CAN/CSA C22.2 No. 60950 Second Edition, UL 60950-1 Second Edition, FCC Class A certified, VCCI Class A, EN 55022/CISPR 22 Class A, EN 60825-1:2007, IEC 60825-1:2007 Class 1, Laser Class 1, CISPR 24, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, IEC 61000-3-2, EN 61000-3-3, IEC 61000-3-3, RFC768, RFC1591, RFC783, RFC792, RFC2460, RFC2925, RFC1213, RFC1493, RFC2674 |
| Localisation: | English / Europe |
| Dimensions & Weight | |
| Width: | 25.4 cm |
| Depth: | 25.5 cm |
| Height: | 4.39 cm |
| Weight: | 2.78 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 45 °C |
| Humidity Range Operating: | 15 - 95% (non-condensing) |
| Humidity Range Storage: | 15 - 90% (non-condensing) |
