Tehnilised andmed
Storage
- Storage drive capacity
- 0 GB
- Storage drive interface
- M.2, Serial ATA
- Supported storage drive interfaces
- M.2, Serial ATA
- Storage drive sizes supported
- 2.5,3.5,M.2
- Maximum supported storage capacity
- 180 TB
- Number of M.2 (M & B) slots
- 2
- RAID support
- Yes
- RAID levels
- 0, 1, 5, 6, 10, JBOD
- Hot-swap drive bays
- Yes
- Supported file systems
- BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
- Storage drives installed
- No
- Total installed storage capacity
- 0 TB
- Number of storage drives supported
- 9
- Installed storage drive type
- No
- Supported storage drive types
- HDD & SSD
Processor
- Processor manufacturer
- AMD
- Processor generation
- AMD Ryzen Embedded V1000 Series
- Processor family
- Ryzen Embedded
- Processor model
- V1500B
- Processor frequency
- 2.2 GHz
- Processor cores
- 4
- Processor threads
- 8
Memory
- Internal memory
- 4 GB
- Internal memory type
- DDR4
- Maximum RAM supported
- 32 GB
- Memory slots
- 2
- Memory form factor
- SO-DIMM
- ECC
- Yes
Network
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 2500 Mbit/s
- Wake-on-LAN ready
- Yes
- Supported network protocols
- SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Ports & interfaces
- USB port
- Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- Ethernet LAN (RJ-45) ports
- 2
Design
- Cooling type
- Active
- Product colour
- Black
- Number of fans
- 2 fan(s)
- Fan diameter
- 9.2 cm
- Fan diameter 2
- 9.2 cm
- Drive bay locking
- Yes
- LED indicators
- Yes
Performance
- Type
- NAS
- Device class
- Home & Home Office
- Backup function
- Yes
- Backup features
- Cloud, iSCSI LUN
- Multilingual support
- Yes
- Number of users
- 512 user(s)
- Noise level
- 20.5 dB
- Snapshot
- Yes
- Web-based management
- Yes
- Access Control List (ACL)
- Yes
- On/off switch
- Yes
- Browser supported
- Chrome,Firefox,Edge,Safari
- System log
- No
Power
- Power supply location
- External
- Power supply unit (PSU) capacity
- 100 W
- Power consumption (typical)
- 37.91 W
- Power consumption (HDD standby)
- 12.33 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50 - 60 Hz
Weight & dimensions
- Width
- 199 mm
- Depth
- 223 mm
- Height
- 166 mm
- Weight
- 2.26 kg
Packaging content
- External power adapter
- Yes
- Cables included
- AC, LAN (RJ-45)
- Power cables quantity
- 1
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 5 - 95%
- Storage temperature (T-T)
- -20 - 60 °C
- Storage relative humidity (H-H)
- 5 - 95%
